Lithicore - Edge 2 Bay Charger

Lithicore Edge 2 Bay Charger is used for charging all kind of lithium batteries such as10440, 14500, 14650, 16340, 16650, 17650, 17670, 18350, 18490, 18500, 18650, 22650, 20700, 21700, 26500, 26650 Cylinder AA/AAA NiMH batteries and Nickel-Cadmium batteries. Lithicore Edge 2 Bay Charger is small and, only install the battery to be charged and it automatically recognizes the type and style of battery, Once connected it turns on and marks the charge with independent led bars for each battery indicating the charge in flashing, the led stays on when it is fully charged. The pulse can charge Lithium Ion, NiMH and Nickel-cadium Batteries.

Features:

• 2.0A constant current charging: When one or two batteries are placed in any slots the charging current is 2A.
• Input standby current: <40mA/100V-230V AC 50Hz/60Hz.
• Cut-off voltage for charging: 4.20 ± 0.05V.
• 1.0A constant current charging: When three or four batteries are placed in the slots the charging current is automatically set to 1A.
• The quiescent current: within 100uA.
• Cut-off current for constant voltage charging: <200mA.
• Activation current (voltage <2.0V): 100mA-200mA.
• Dual battery charger.
• LED display function.
• Battery type recognition.
• Fire-retardant material.
• Protects from overcharge and short circuit.

Specifications:
Input: AC 100-240V 50/60Hz
Output: 4.2V/2A*1/2A*2 4.2V/1A*3/1A*4
